Thicker and bigger …
Apart from the combi lines 110C (CAT+Power), 111C (CAT+Power+DMX), 202 (2xCAT+2xDMX) and 212(2xCAT+2xDMX+Power) we also offer the extended variants SC-MONOCAT POWER 414 and 810. In addition to the power line, the SC-MONOCAT POWER 414 has four CAT and four DMX lines each, the SC-MONOCAT POWER 810 with its super robust, notch and cold resistant PUR jacket has eight CAT lines.
Advantages:
- LAN signal transmission incl. mains supply in one cable
- LAN cable also usable as an additional control line
- LAN line suitable for audio transmission
Application:
- Mobile applications
- Control of DMX lighting consoles
- Analogue + digital audio multipair with LAN and power supply
- Permanent Installation
Teknisk info
| Application | hybrid cable |
| Application area |
|
| BPVo-Euroclass | Fca |
| Capacity wire/wire at 1m (network) | 44 pF |
| Colour | black |
| Colour detailed | black |
| Conductor insulation material | Foam/Skin-PE |
| Fire load per m | 3,25 kWh |
| Height | 27 mm |
| Impedance (network) | 100 Ohm |
| Inner conductor (AES/EBU, DMX) |
|
| Inner conductor (network) | 8 |
| Inner conductor (power) |
|
| Inner conductor Ø (network) | 0,51 mm |
| Insulation resist. per 1km (power) | 5 G Ohm |
| Jacket material | PVC |
| Jacket Ø | 27 mm |
| Kanaler | 4xCAT+4xDMX+POWER |
| Materiale | PVC |
| Max. section length | 110 m |
| Nominal voltage (power) | 500 V |
| Number of Channels (network) | 4 |
| Number of Channels (power) | 1 |
| Operating voltage (power) | 300 V |
| Packing | bulk stock |
| Properties |
|
| Shielding (AES/EBU, DMX) | Copper braiding tin-plated |
| Shielding (network) | AL / PT-foil + Copper braiding tin-plated |
| Shielding factor | 1 |
| Signal transmission | symmetrical |
| Style variant | round |
| Temperature max. | 75 °C |
| Temperature min. | -30 °C |
| Type | AES/EBU DMX512 |
| UV-resistant | Yes |
| Weight per 1 m | 850 g |
| Width | 27 mm |
